You've decided to use some of the excess heat from your fireplace to warm another room.

You have a suitable duct route, a heat-resistant inline fan, and an idea of where you want the warm air to go.

But there's one important question left:

Where should you actually install the fan?

Should it be immediately above the fireplace? Somewhere in the middle of the duct? Or as close as possible to the room receiving the warm air?

There isn't one position that's perfect for every installation. The best location depends on air temperature, duct length, accessibility, noise, airflow resistance, and the specifications of the fan itself.

Let's look at how to choose the right position.

First, Understand What the Fan Is Moving

Before discussing fan position, there's an important distinction to make.

A fireplace hot-air distribution system moves heated air, not smoke or combustion gases.

The fan should never be connected directly to the chimney or fireplace flue unless the complete system has been specifically engineered for that purpose.

A typical hot-air distribution system collects warm air from an appropriate area around a fireplace or heating installation and transfers it through ductwork to another part of the building.

A simplified system might look like this:

Fireplace / heat source → warm-air intake → duct → heat-resistant fan → duct → outlet in another room

The exact layout will depend on the fireplace and the building, but this basic principle applies to many residential heat-distribution installations.

Should the Fan Be Installed Close to the Fireplace?

It can be tempting to place the fan immediately next to the hot-air intake.

After all, if the purpose is to move hot air, putting the fan close to the heat source may seem logical.

But closer isn't automatically better.

The closer the fan is to the fireplace or hot-air collection point, the higher the air temperature passing through it is likely to be.

This makes the fan's maximum operating temperature extremely important.

A conventional inline ventilation fan designed for normal room-temperature air should not be used simply because it fits the duct.

Even a heat-resistant fan has a specified maximum operating temperature that must not be exceeded.

If the air at the proposed fan location is hotter than the fan's rated operating temperature, the fan needs to be moved farther along the duct or the system needs to be redesigned.

Why Installing the Fan Farther Along the Duct Can Help

Hot air loses some heat as it travels through ductwork.

This means the air temperature several meters away from the fireplace may be lower than it is immediately at the collection point.

Installing the fan farther downstream can therefore reduce the thermal stress placed on the motor, bearings, wiring, and other fan components.

This can be particularly useful when the temperature near the heat source approaches the fan's maximum rating.

However, don't simply assume that a certain duct length will reduce the temperature enough.

The actual temperature depends on several factors:

  • Temperature at the intake
  • Duct length
  • Duct diameter
  • Airflow speed
  • Duct insulation
  • Surrounding temperature
  • Fireplace output
  • System construction
  • The safest approach is to determine the actual temperature at the planned fan location under realistic operating conditions.

Is the Middle of the Duct a Good Position?

In many installations, somewhere between the heat source and the destination room can be a practical location for the inline fan.

This may provide several advantages.

The fan can be far enough from the hottest part of the system to reduce thermal exposure, while still being positioned effectively within the duct run.

A central or intermediate location may also make it easier to find an accessible installation point in an attic, service area, utility space, or other suitable location.

But airflow alone shouldn't determine the position.

You also need to think about maintenance.

Keep the Fan Accessible

This is one of the most practical pieces of advice when planning a DIY installation.

Don't install the fan somewhere you'll never be able to reach again.

Even a high-quality inline fan may eventually require inspection, cleaning, electrical work, or replacement.

If the fan is permanently sealed behind plasterboard, built into an inaccessible ceiling, or buried underneath insulation without an access point, a simple maintenance task can become a renovation project.

Try to position the fan somewhere that provides reasonable access to:

  • The fan body
  • Electrical connections
  • Duct connections
  • Thermostat or controller, if fitted
  • Mounting hardware

If the fan must be concealed, consider providing an inspection hatch.

What About Installing the Fan Near the Destination Room?

Another possibility is placing the fan closer to the room receiving the warm air.

From a temperature perspective, this can be beneficial because the air may have cooled somewhat by the time it reaches that point.

There can also be practical advantages if the destination side provides easier access for installation and maintenance.

However, there is one potential disadvantage:

noise.

Although a good inline fan can operate relatively quietly, placing the motor immediately behind a bedroom or living-room outlet may make its sound more noticeable.

Air movement itself can also generate noise at the grille.

If quiet operation is important, consider the distance between the fan and occupied spaces, as well as how vibration could travel through the ductwork and building structure.

Think About Noise and Vibration

Fan noise isn't determined only by the motor.

Vibration can travel through rigid ductwork and mounting surfaces, turning parts of the installation into sound transmitters.

A fan installed directly against a lightweight wall or ceiling structure may therefore sound louder inside the room than the same fan installed in a more isolated service area.

Good installation practices can help.

Avoid unnecessary mechanical tension in the ductwork, secure the fan correctly, and follow the manufacturer's mounting instructions.

Where appropriate for the specific temperature and installation, suitable connections and mounting methods can also help reduce vibration transfer.

This is another reason why installing the fan a reasonable distance from bedrooms and quiet living areas can be worthwhile.

Should You Push or Pull the Hot Air?

Homeowners sometimes wonder whether the fan should be placed near the beginning of the system to "push" the warm air or farther downstream to "pull" it through the duct.

For a properly designed inline system, both sides of the fan are part of the same airflow path.

The more important considerations are usually:

temperature, airflow resistance, accessibility, noise, and the fan manufacturer's installation requirements.

Instead of focusing only on whether the fan is pushing or pulling, look at the complete duct system.

A poorly designed duct route with excessive bends and restrictions will reduce performance regardless of where the fan is installed.

Keep the Duct Route Simple

Fan position and duct design go together.

Every bend, restriction, grille, and length of duct creates resistance to airflow.

For better performance:

  • Keep the duct route reasonably short
  • Avoid unnecessary sharp bends
  • Use the correct duct diameter
  • Avoid crushing or restricting flexible duct
  • Use suitable heat-resistant duct materials
  • Insulate the duct where heat loss would otherwise be significant
  • Choose outlet grilles that don't unnecessarily restrict airflow

Moving the fan won't solve a system that has excessive airflow resistance.

Why Insulated Ductwork Matters

If your goal is to move heat from one room to another, losing that heat inside an attic or unheated service space isn't particularly useful.

Insulating the hot-air duct can reduce heat loss between the fireplace and the destination room.

It can also change the temperature reaching the fan.

A well-insulated duct retains heat more effectively, which is good for delivering warm air but also means that the air may remain hotter farther along the duct.

This is another reason not to estimate fan temperature based only on distance from the fireplace.

Measure or properly assess the temperature at the actual fan location.

Using a Heat-Resistant Inline Fan

For fireplace heat distribution, the fan needs to be suitable for the expected operating temperature.

MMotors VOK-T heat-resistant inline duct fans are designed for ventilation and heating applications where the transported air can reach temperatures of up to 150°C.

The VOK-T range is available in several duct sizes and airflow capacities, making it possible to select a model according to the installation.

The motors use double-encapsulated ball bearings and can be installed in horizontal or vertical duct systems when installed according to the product requirements.

This mounting flexibility can be particularly useful when the available installation space determines where the fan needs to be positioned.

A Thermostat Can Make the System Smarter

A thermostat is a particularly useful addition to a fireplace hot-air distribution system.

Without temperature control, switching the fan on while the fireplace is cold could simply move cool air into the second room.

A temperature-controlled system can wait until useful heat is available before activating the fan.

For thermostat-equipped MMotors VOK systems, the fan can switch on when the air temperature reaches approximately 50°C and switch off after it falls to approximately 35°C.

This allows the hot-air distribution system to operate more automatically and reduces the need to switch the fan manually every time the fireplace is used.

Don't Forget the Return Air Path

There is another part of the system that can easily be overlooked.

If you're moving air from the fireplace room into another room, that air needs a way to circulate back.

Imagine transferring warm air into a bedroom with a tightly closed door. As pressure builds slightly inside the room, airflow through the duct can decrease.

A return path can be provided by:

  • An open doorway
  • Sufficient clearance underneath the door
  • A transfer grille
  • A dedicated return-air path

Thinking in terms of an air circulation loop rather than a one-way pipe can improve the effectiveness of the complete system.

So, Where Is the Best Place for the Fan?

For many residential hot-air distribution systems, a practical fan location is some distance away from the hottest air collection point, installed inline in an accessible section of the duct.

This can offer a good balance between temperature exposure, accessibility, airflow, and noise.

But there is no universal distance such as "one meter from the fireplace" or "exactly halfway through the duct."

The correct position depends on the actual system.

A good installation location should meet four basic conditions:

  • The air temperature is safely within the fan's rated operating range.
  • The fan is installed in an approved orientation.
  • The fan remains accessible for inspection and maintenance.
  • Its location doesn't create unnecessary noise or vibration in occupied rooms.

If all four conditions are met, you're much closer to choosing the right position.

Important Safety Reminder

A heat-resistant hot-air fan is not a fireplace smoke extractor.

Fans such as the MMotors VOK-T are designed to move heated air in suitable heating and ventilation systems. They should not be connected directly to a fireplace flue to extract smoke or combustion gases.

Temperatures inside a flue can be significantly higher than those in a hot-air distribution system, and combustion gases introduce additional safety risks.

Always follow the fireplace manufacturer's requirements, the fan manufacturer's specifications, and applicable fire, building, and electrical regulations.

If you're uncertain about the design of the hot-air collection area, duct routing, fire separation, or electrical installation, consult a qualified heating or ventilation professional before proceeding.

Good Fan Positioning Starts With the Whole System

There's no single perfect location for every fireplace hot-air distribution fan.

Installing the fan very close to the fireplace may expose it to unnecessarily high temperatures. Installing it too close to the destination room may make operating noise more noticeable. Hiding it somewhere inaccessible can make future maintenance unnecessarily difficult.

The best position is therefore a balance.

Consider the temperature, duct route, airflow resistance, noise, installation orientation, and accessibility together.

At MMotors, our VOK-T heat-resistant inline duct fans are designed specifically for demanding heating and ventilation applications, with models capable of transporting hot air at temperatures up to 150°C.

Combined with suitable heat-resistant ductwork, proper installation, and appropriate temperature control, the right fan can help you distribute fireplace heat more effectively and make better use of the warmth your home is already producing.
